| 22.2mm x 156mm (7/8" x 6 1/8") |
1 |
| 22.5mm x 152.5mm (7/8"x 6") |
2 |
| 25.4mm x 121 mm (1"x 4 3/4") |
3 |
| 25.4mm x 127.5 mm (1"x 5") |
4 |
| 25.4mm x133.5 mm (1"x 5 1/4") |
5 |
| 25.4mm x 145 mm (1"x 5 3/4") |
6 |
25.4mm x 153 mm (1"x 6")
25.4mm x 156.5 mm (1"x 6")
25.4mm x 165.5 mm (1"x 6 1/2") |
7
8
9 |
| 25.4mm x 177 mm (1"x 7") |
10 |
| 25mm x 57.5 mm (1"x 2 1/4") |
11UPPER |
| 26mm x 56.5 mm (1"x 2 1/4") |
11LOWER |
| 25.6mm x 162mm (1"x 6 3/8") |
12 |
| |
|
Mortise Lock Dimensions:
| Metric (D x OL) |
Template |
16mm x 72 mm* (5/8" x 2 7/8")
16mm x 107 mm* (5/8" x 4 1/4") |
A
B |
| 19mm x 78 mm* (3/4" x 3 1/8") |
C |
| 19mm x 109 mm* (3/4" x 4 1/4") |
D |
| |
|
*These are maximum mortise lock case (body) lengths, unless radius ends are squared with a chisel. Actual length of mortise is 7mm longer. |
|
