- Highly efficient filter process removes particles > 5 μm and fine dust particles > 1 μm
- Designed to clean the air in workshops and exhibition rooms
- Ideal supplement to a stationary extraction system without fine filter
- In larger production areas also the use of several unitsrecommended directly at the machine or distributed in the room
- Adjustable in three steps
- Time recording for automatic switch-off
- Convenient operation via remote control
- Pre-filter easy to remove and clean
Examples, how often the air in certain rooms should be changed per hour:
- Assembly halls: 4 - 8 times
- Workshops: 8 - 10 times
- Laboratories: 8 - 15 times
- Paint-spray rooms: 25 - 50 times
Dimensions and weights
Length approx. 770 mm
Width/depth approx. 610 mm
Height approx. 310 mm
Weight approx. 25 kg
Electrical Data
Motor input 300 W
Supply voltage 230 V
Mains frequency 50 Hz
Filter
Filter category filter net G4
Filter category inner filter F6
Noise emission
Max. sound pressure level 69 dB(A)
Volume flow
Max. volume flow, low level 945 m³/h
Max. volume flow, medium level 1035 m³/h
Max. volume flow, high level 1675 m³/h
VPE 1
No details given.
