Dimensions and weights
Length approx. 565 mm
Width/depth approx. 275 mm
Height approx. 840 mm
Weight approx. 36.5 kg
Drilling performance
Drilling performance steel (S235JR) 15.5 mm
Continuous drilling performance steel (S235JR) 12 mm
Drilling table
Workspace length 235 mm
Workspace width 220 mm
T-groove type diagonal
T-groove size 12 mm
Max. distance spindle - drilling table 325 mm
Electrical Data
Supply voltage 230 V
Mains frequency 50 Hz
Machine base
Max. distance spindle - machine base 530 mm
Work area length 170 mm
Work area width 180 mm
Machine base T-groove size 14 mm
Machine base T-groove number 2
Machine base T-groove spacing 148 mm
Length 210 mm
Width 215 mm
Motor(s)
Spindle motor drive output 0.49 kW
Speed range
Speed range 680 – 2700 min¯¹
Number of gears 5
Spindle
Quill stroke 65 mm
Spindle chuck MK 2
Reach 152 mm
VPE 1
