Dimensions and weights
Column diameter 60 mm
Length approx. 568 mm
Width/depth approx. 319 mm
Height approx. 849 mm
Weight approx. 28.5 kg
Drilling performance
Drilling performance steel (S235JR) 15.9 mm
Continuous drilling performance steel (S235JR) 14 mm
Drilling table
Workspace length 200 mm
Workspace width 200 mm
T-groove type diagonal
T-groove size 14 mm
T-groove number 2
Rotation 360 °
Angle 45 °
Load bearing capacity 12 kg
Max. distance spindle - drilling table 319 mm
Electrical Data
Drive motor output 0,45 kW
Supply voltage 230 V
Mains frequency 50 Hz
Machine base
Max. distance spindle - machine base 518 mm
Work area length 145 mm
Work area width 143 mm
Speed range
Speed range 600 – 2400 min¯¹
Number of gears 5 Steps
Spindle
Quill stroke 65 mm
Spindle chuck MK 2
Reach 127 mm
VPE 1
