In a class of its own: heavy-duty 3000 Watt (3.8 hp) motor for extreme 185 mm (7 5/16 in.) cutting performance!
The saw´s handling and behavior are refined by smooth starting, constant speeds under load, speed reduction and overload protection.
The easy-to-use stop system, the low noise emission and the remote-controlled retractable knife guard make your work much easier.
The very smooth-running height adjustment with its clearly legible scale and an effective brake also ensure perfect cutting results and optimum operator safety.
Applications
- Cross-cutting and rip cuts
- Bevel cuts up to 60°
- General joining work
- Compatible materials include solid wood, laminated beams, insulating materials, composite boards
Advantages
- With CUprex, the high-performance motor
- Unique ratio between maximum stability and minimum weight.
- High quality standard means lower machine costs and longer service life.
- Constant cut display for 0° - 60° - due to exact centre of rotation, which is on the unterside of the base plate.
Cutting depth 105 - 185 mm
Cutting depth 4 1/8 - 7 5/16 in
Cutting depth (a) 105 mm
Cutting depth (b) 185 mm
Cutting depth at 45° 74 - 131 mm
Cutting depth at 45° 2 15/16 - 5 3/16 in
Cutting depth at 60° 53 - 93 mm
Cutting depth at 60° 2 1/16 - 3 11/16 in
Tilt range 0 - 60 °
Nominal No. of strokes – no load 1400 - 1700 1/min
Nominal power input 3000 W
Nominal power input 4.0 hp
Weight 16,1 kg
Weight 35.5 lbs
Universal motor 230 V / 50 Hz
- 1 Allen key 6 mm; Ref. No. 093081
- 1 TCT saw blade 450 x 2.5/4.2 x 30 mm (17 11/16 in.), AT, 20 teeth; Ref. No. 092536
- 1 Parallel guide fence
- 1 Mains cable 10 m (32.8 ft); Ref. No. 087612
- 1 adapter cable UKCA
- boxed
