Compact light weight, suitable also for one-handed transport.
Enormous cutting performance due to extremely powerful universal motor and large saw blade.
Sliding function for wide work pieces.
Easy transport thanks to ergonomically-designed handles and saw head lock.
Robust die-cast aluminium design for highest demands.
Effective dust extraction via integrated dust scoop.
Starting current limitation prevents the actuation of the lock on start-up.
Fast and precise setting of common angles using stop points.
Laser for exact display of the cutting line (mains powered, no batteries required).
Infinitely extendable table width extension, removable to put long panels, slabs etc. underneath.
Bright LED work light for illumination of the cutting line (mains powered, no batteries required).
High sliding rear fence profiles for safe sawing.
Material clamp for secure fixing of the work piece from the top or front.
Depth stop for easy creation of grooves.
Saw head can be inclined to the left, with additional angle range for undercuts.
All scales and operating elements are visible from the working position and can be operated intuitively.
Easy saw blade change by means of spindle lock: No dismantling of the pendulum protective cover required.
Dimensions 850 x 515 x 615 mm
Maximum cutting width 90°/45° 305 mm/205 mm
Maximum cutting depth at 90°/45° 105 mm/67 mm
Turntable setting left/right 47 °/47 °
Saw blade tilt left/right 47 °/2 °
Saw blade Ø 305 x 30 mm
Motor power 2000 W
No-Load Speed 3.700 /min
Revolutions at rated load 2.600 /min
Max. cutting speed 60/197 m/s
Weight 19,6 kg
Carbide saw blade (56 teeth)
2 Table length extensions
Length guide
Material clamp
Tool for saw blade change
Cable winder
Chip collection bag
